Production Floor
Automated production areas support consistent PCB fabrication from prototype builds to volume manufacturing.
ABOUT CIRCFAB
Professional PCB
Manufacturing & Assembly
CircFab Solution Ltd is a professional PCB manufacturer with advanced fabrication and assembly capabilities. From rapid prototyping to high-volume production, we deliver precision-engineered printed circuit boards that meet demanding industry standards.
Board Inspection
Finished boards are reviewed under controlled lighting to confirm solder quality, surface finish, and visual consistency.
Our Manufacturing Excellence
CircFab Solution Ltd is a professional PCB manufacturer and electronics assembly company with modern production facilities. We specialize in delivering high-quality printed circuit board fabrication and assembly solutions for clients across aerospace, medical, automotive, telecommunications, and industrial sectors.
20+
countries served
10,000+
boards daily capacity
Modern Manufacturing Facility
E Pecos Rd & S 80th St
Our Manufacturing Facility at E Pecos Rd & S 80th St is equipped with climate-controlled clean rooms and automated production lines. The facility is designed to support high-volume manufacturing while maintaining strict quality control and environmental standards.
- Climate-controlled clean rooms (Class 10,000)
- Automated SMT production lines (8 lines)
- Advanced AOI and X-ray inspection systems
- Dedicated prototype and NPI workshop
- ISO 14001 environmental management
- ESD-protected manufacturing areas
Inside Our PCB Factory
Production, inspection, drilling, and wet process areas built for consistent PCB manufacturing quality.
Factory Area
Production Floor
Automated production areas support consistent PCB fabrication from prototype builds to volume manufacturing.
Factory Area
Board Inspection
Finished boards are reviewed under controlled lighting to confirm solder quality, surface finish, and visual consistency.
Factory Area
Drilling Station
Precision drilling and routing equipment helps maintain tight tolerances for vias, slots, and finished board outlines.
Factory Area
Wet Process
Wet process lines manage cleaning, plating, and surface preparation steps that directly affect board reliability.
Factory Area
Factory Gallery
A broader look at fabrication, inspection, drilling, and assembly areas working together in one production flow.
Manufacturing Process
Systematic production workflow ensuring consistent quality at every stage
01
Material Preparation
Incoming material inspection and storage under controlled conditions
02
Imaging & Etching
Precision circuit pattern transfer using direct imaging technology
03
Layer Lamination
Multi-layer board pressing with controlled temperature and pressure
04
Drilling & Plating
High-precision mechanical and laser drilling with copper plating
05
Surface Finish
Application of ENIG, HASL, or other surface finishes per specification
06
Testing & Inspection
100% electrical testing, AOI inspection, and final quality verification
Production Specifications
Technical capabilities for diverse PCB requirements
1-32 Layers
Layer Range
3/3 mil (0.075/0.075mm)
Min Trace/Space
24-48 hours for prototypes
Prototype Lead Time
HASL, ENIG, Immersion Silver, OSP
Surface Finishes
0.4mm - 6.0mm
Board Thickness
Up to 24" x 24"
Maximum Size
Blind/Buried Vias, Microvias
Via Technologies
IPC Class 3
Quality Standard
Comprehensive PCB Solutions
From bare board fabrication to complete PCBA, we offer end-to-end manufacturing services with full traceability and quality assurance.
Advanced PCB Fabrication
Our manufacturing facility is equipped with modern PCB production lines capable of fabricating single-sided, double-sided, and multi-layer boards up to 32 layers. We support various materials including FR-4, High-Tg, Rogers, aluminum, and flex substrates with precision impedance control and advanced via technologies.
Professional PCB Assembly (PCBA)
We provide comprehensive SMT and through-hole assembly services with automated pick-and-place machines, reflow ovens, and wave soldering systems. Our assembly capabilities include fine-pitch components down to 01005, BGA, QFN, and complex mixed-technology boards with 100% AOI inspection and functional testing.
Quality Assurance & Testing
Quality is at the core of our manufacturing process. We implement strict IPC-A-610 Class 2 and Class 3 standards, 100% electrical testing, Automated Optical Inspection (AOI), X-ray inspection for BGA components, and flying probe testing. Our facility maintains ISO 9001 certification and UL recognition.
Why Choose CircFab?
Direct factory advantages for superior PCB manufacturing
Factory-Direct Control
Unlike trading companies, we manage the entire manufacturing process in-house—from raw material sourcing to final shipment—ensuring competitive pricing and real-time production updates.
Rapid Prototyping
Our efficient production lines enable 24-48 hour turnaround for prototype orders, helping you accelerate product development and time-to-market.
Design Support
Our engineering team provides free Design for Manufacturability (DFM) review to optimize your PCB designs for production efficiency and cost-effectiveness.
Certifications & Standards
Committed to international quality and environmental standards
ISO 9001:2015
Quality Management System
ISO 14001:2015
Environmental Management
UL Certified
Safety Recognition (E-file)
IPC-A-610
Acceptability of Electronic Assemblies
IPC-6012
Qualification for Rigid PCBs
RoHS Compliant
Hazardous Substance Restriction
Ready to Start Your PCB Project?
Upload your Gerber files today for an instant quote. Our engineering team will review your design for manufacturability and provide expert recommendations.
